12V 120Ah (1.54kWh) Pro Series - LiFePO4 Cranking & Deep Cycle Lithium Battery (Dual Purpose)

The Bronze 90° Elbow (Female‑Female BSP) is a heavy‑duty threaded pipe fitting designed to change the direction of piping by 90°, creating a secure and reliable joint between two female‑threaded pipes or fittings. Made from solid bronze, this elbow provides excellent corrosion resistance and durability, making it ideal for marine, industrial, and general plumbing installations where long‑lasting performance is essential.

🔧 Key Features

Solid bronze construction — highly resistant to corrosion, especially in saltwater and harsh environments.

90° angle — enables a compact directional change in pipe runs without additional fittings.
Female‑to‑female BSP threads — compatible with standard British Standard Pipe (BSP) systems for secure connections.
Compact, snag‑free body — minimizes bulk and simplifies routing in tight spaces.
Reliable sealing — precise threading for leak‑resistant performance.

⚓ Typical Applications

This 90° elbow fitting is perfect for:

Marine plumbing — freshwater and seawater piping, bilge, deck wash, and cooling systems.
Industrial piping — fluid transfer, compressed air, and general utility lines.
Domestic systems — potable water, heating and cooling circuits.

Any installation requiring a direction change in threaded pipe runs without compromising system integrity.

💡 Why Use a Bronze Elbow Fitting?

Bronze threaded fittings deliver exceptional corrosion resistance and mechanical strength, ensuring dependable performance even in challenging environments. The 90° elbow simplifies piping layouts, reduces the need for multiple components, and supports tight, leak‑free connections in both new installations and retrofit projects.

Configuration:4S4P

Chemistry:LiFePO4

Ah Capacity:120Ah

Max Continuous Discharge Amps:150A

Max Charge Current Amps:100AMax

Discharge Peak Current Amps:800A @ 10sSeries | Parallel:Max (4) in Series, Max (16) in Parallel

Voltage:12.8VMax Charge Voltage:15.4VOperating Voltage Range:10.0 - 15.4VTemperatureCharge Temp Range:-20°C (-4°F) / 55°C (131°F) (with heating)

Discharge Temp Range:-20°C (-4°F) / 60°C (140°F)Storage Temp:0°C (32°F) / 35°C (95°F)

Weight:29.7 lbsDimensionsLength:12.25(inches)Width:6.75(inches)Height:9(inches)

To properly charge your Epoch Batteries, you will want to verify that any charging component in your system is capable of being programmed for the following specifications.

Charging components can include, but are not limited to converters, inverter chargers, solar charge controllers, DC to DC chargers, etc.

Bulk/Absorption: 14.2V – 14.6V

Absorption Time: Two batteries in parallel connections require 30 minutes 200Ah

Float: 13.4V – 13.8V

Equalization: 14.4V/ Disabled

Temperature Compensation: 0/

DisabledCharge Rate: 50% of the battery or battery bank capacity

Battery Charge Temperature Range: 32°F (0°C) to 131°F (55°C)

Battery Discharge Temperature Range: -4°F (-20°C) to 140°F (60°C)

Cell Charge Temperature: 32°F (0°C) to 131°F (55°C)

Cell Discharge Temperature: -4°F (-20°C) to 140°F (60°C)

NOTE: Not all chargers are capable of multistage charging. If yours is not, you will want to verify it can be programmed for the Bulk/Absorption voltage and have the other items mentioned disabled if applicable. Consult your charger's manual or the manufacturer.
